Designing a Chess Game: The Roblox New Grad Interview

Designing a Chess Game is a frequently asked object oriented design even for new grads.

In this post, we explore the key aspects of designing a chess game with an object-oriented approach, focusing on core object modeling, encapsulation, polymorphism, design patterns, object relationships, scalability, and technical considerations, together with code snippets.

System Design Diagram — Design Chess Game

1. Core Object Modeling

ChessBoard

The ChessBoard class manages the state of the game and provides methods for piece placement and movement tracking. Key considerations include:

• Data Structure for Board Representation: Should we use a 2D array (8x8 matrix), a hashmap, or a graph-based approach? A 2D array is straightforward, while a hashmap can optimize lookup times for sparse board representations.
• Encapsulation of Board State: The board should provide an interface to query and modify positions without exposing the internal representation.
• Move History Storage: The board should maintain a history of moves for undo functionality and replay features.

class ChessBoard {
private Piece[][] board;
private List moveHistory;

public ChessBoard() {
this.board = new Piece[8][8];
this.moveHistory = new ArrayList<>();
initializeBoard();
}

private void initializeBoard() {
// Place pieces in initial positions using PieceFactory
}

public void movePiece(Position from, Position to) {
moveHistory.add(new Move(from, to, board[to.getX()][to.getY()]));
board[to.getX()][to.getY()] = board[from.getX()][from.getY()];
board[from.getX()][from.getY()] = null;
}
}

Piece and Its Variants

• The Piece class is an abstract class representing a chess piece.
• Each piece type (Pawn, Rook, Knight, Bishop, Queen, King) extends this class and implements movement rules.
• Encapsulation: Each piece controls its own move logic through polymorphism.

abstract class Piece {
protected Position position;
protected boolean isWhite;

public Piece(Position position, boolean isWhite) {
this.position = position;
this.isWhite = isWhite;
}

public abstract boolean isValidMove(Position newPosition, ChessBoard board);
}

2. Design Patterns in Chess Game Design

a) Factory Pattern

Used for creating chess pieces dynamically based on type.

class PieceFactory {
public static Piece createPiece(String type, boolean isWhite) {
switch (type) {
case "Pawn": return new Pawn(isWhite);
case "Knight": return new Knight(isWhite);
case "Bishop": return new Bishop(isWhite);
case "Rook": return new Rook(isWhite);
case "Queen": return new Queen(isWhite);
case "King": return new King(isWhite);
default: throw new IllegalArgumentException("Invalid piece type");
}
}
}

b) Strategy Pattern

Encapsulates different move validation strategies for each piece.

interface MoveStrategy {
boolean isValidMove(Position from, Position to, ChessBoard board);
}

class BishopMoveStrategy implements MoveStrategy {
public boolean isValidMove(Position from, Position to, ChessBoard board) {
return Math.abs(from.getX() - to.getX()) == Math.abs(from.getY() - to.getY());
}
}

Each piece class uses a different move strategy:

class Bishop extends Piece {
public Bishop(boolean isWhite) {
super(isWhite, new BishopMoveStrategy());
}
}

c) Observer Pattern

Used for notifying the UI or players about game state changes.

interface GameObserver {
void onMoveMade(Move move);
}

class ChessGameUI implements GameObserver {
public void onMoveMade(Move move) {
System.out.println("Move made: " + move);
}
}

d) Command Pattern

Used for implementing undo/redo functionality.

interface Command {
void execute();
void undo();
}

class MoveCommand implements Command {
private ChessBoard board;
private Position from, to;
private Piece capturedPiece;
public MoveCommand(ChessBoard board, Position from, Position to) {
this.board = board;
this.from = from;
this.to = to;
}
public void execute() {
capturedPiece = board.getPiece(to);
board.movePiece(from, to);
}
public void undo() {
board.movePiece(to, from);
board.placePiece(to, capturedPiece);
}
}

e) Singleton Pattern

Ensures only one instance of GameManager exists at a time.

class GameManager {
private static GameManager instance;

private GameManager() {}

public static GameManager getInstance() {
if (instance == null) {
instance = new GameManager();
}
return instance;
}
}

3. Scalability Considerations

Database Choice and Storage Strategies

• Relational Database (PostgreSQL, MySQL): Suitable for structured data like player profiles, match history, and ELO ratings.
• NoSQL (MongoDB, DynamoDB): Useful for storing real-time game states and move history in a flexible JSON format.
• Redis: Acts as an in-memory cache to store active game sessions, reducing database load and improving response times.
• Sharding and Replication: For high scalability, distribute game sessions across multiple database instances and replicate read-heavy data.

Schema Design

Relational Database Schema (PostgreSQL/MySQL)

CREATE TABLE players (
id SERIAL PRIMARY KEY,
username VARCHAR(255) UNIQUE NOT NULL,
elo_rating INT NOT NULL
);

CREATE TABLE games (
id SERIAL PRIMARY KEY,
white_player_id INT REFERENCES players(id),
black_player_id INT REFERENCES players(id),
status VARCHAR(50) CHECK (status IN ('ongoing', 'completed', 'abandoned')),
start_time TIMESTAMP DEFAULT NOW(),
end_time TIMESTAMP
);

CREATE TABLE moves (
id SERIAL PRIMARY KEY,
game_id INT REFERENCES games(id),
move_number INT NOT NULL,
piece VARCHAR(50) NOT NULL,
from_position VARCHAR(5) NOT NULL,
to_position VARCHAR(5) NOT NULL,
timestamp TIMESTAMP DEFAULT NOW()
);

NoSQL Schema (MongoDB)

{
"game_id": "12345",
"players": {
"white": "user1",
"black": "user2"
},
"moves": [
{ "move_number": 1, "piece": "Pawn", "from": "e2", "to": "e4" },
{ "move_number": 2, "piece": "Knight", "from": "g8", "to": "f6" }
],
"status": "ongoing",
"start_time": "2023-07-01T12:00:00Z"
}

4. Handling Large Numbers of Games

• Game State Management: Active games are stored in Redis for quick access, while completed games are persisted in a relational or NoSQL database.
• Session Management: Each game instance is assigned a unique session ID, allowing efficient retrieval.
• Event Sourcing: Instead of storing only the final board state, maintain a log of all moves to enable replay and rollback functionalities.

5. Performance Optimization

• Bitboards (64-bit integers) can be used for fast move computations by representing the board as a set of bitmaps.
• Precomputed attack tables can optimize check and checkmate detection.
• Parallel Processing: AI computations, such as Minimax and Alpha-Beta pruning, can be offloaded to separate threads or a distributed computing environment.
• Load Balancing: Distribute game requests across multiple application instances using a load balancer.

6. AI and Multiplayer Scalability

• AI Algorithms: Minimax with Alpha-Beta pruning, Monte Carlo Tree Search (MCTS), or neural network-based approaches like AlphaZero.
• Multiplayer Game State Synchronization: WebSockets for real-time move updates, ensuring seamless synchronization across clients.
• Conflict Resolution in Concurrent Games: Implement atomic operations and locks to prevent simultaneous conflicting moves.

7. Rule Variants Support

• Chess960 (randomized starting positions) can be implemented by modifying the board initialization logic.
• Custom game modes with different board sizes or rules can be handled by modifying the piece factory and move strategies.

8. Spectator Mode and Game History

• Allow users to watch ongoing games with real-time updates.
• Store move history in PGN (Portable Game Notation) format for replay analysis.
• Implement a replay system that allows step-through navigation of past games.

Full Answer: https://bugfree.ai/practice/object-oriented-design/chess-game/solutions/oYmdfuB0ooqAuX1d
