Vending Machine Transaction State Diagram

Vending Machine OOD: Make Refund a First-Class Transaction State

When designing a vending machine (or any payment+fulfillment system), model a refund as a first-class state in the Transaction lifecycle — not as an ad-hoc side effect.

Why this matters

Failures happen after money moves: the payment gateway can accept funds, then the dispenser jams or a network timeout interrupts dispensing. If you don't model that possibility explicitly, you can't reliably enforce idempotency, inventory correctness, or accurate logs.
If refund is an afterthought, you risk double-decrementing stock, missing refunds, inconsistent logs, and hard-to-reproduce charge disputes.

Core rule (the interviewer favorite)

Decrement stock only after the item is successfully DISPENSED.
Trigger a refund only when the Transaction is in PAID and dispensing cannot be completed (FAILED).

Transaction state machine (recommended)

INITIATED -> PAID -> DISPENSED
PAID -> FAILED -> REFUNDED
(Optionally) PAID -> CANCELLED -> REFUNDED

In other words:

INITIATED: user started purchase, awaiting payment.
PAID: payment confirmed, awaiting dispensing.
DISPENSED: physical item delivered — now safe to change inventory.
FAILED: dispensing failed (jam, timeout, etc.). From here, the system should either attempt retries or move to REFUNDED.
REFUNDED: payment reversed (or credit issued).

Best practices and implementation notes

Idempotency and single source of truth
Use a Transaction record as the single source of truth for each purchase attempt (tx_id, user_id, item_id, state, timestamps, gateway_ids, attempts).
All operations (decrement inventory, call dispenser, call refund API) should be guarded by the Transaction state. If a request is retried, examine the tx state and perform only the actions that haven't been done yet.
Decrement inventory only on DISPENSED
Do not decrement stock when payment succeeds. Only mark inventory as sold once DISPENSED is recorded.
This avoids inventory drift if dispensing fails.
Refund only from PAID (or FAILED) state
When dispensing fails, transition PAID -> FAILED, then trigger refund flow and transition to REFUNDED once the refund is confirmed (or scheduled).
Make refund calls idempotent (use payment gateway idempotency keys) and persist external refund ids on the Transaction.
Concurrency and consistency
Use optimistic locking (version numbers) or DB transactions when updating inventory and transaction states to avoid race conditions.
Consider reservation patterns: optionally reserve stock on PAID but keep a separate reserved_count that is reconciled only on DISPENSED vs REFUNDED.
Asynchronous flows and retries
Use an event queue for physical dispense attempts and refund requests. The queue consumer reads tx state, attempts the operation, updates state, and emits events.
Implement retry/backoff logic for hardware and network errors, then escalate to FAILED -> REFUNDED after a threshold.
Logging, monitoring, and reconciliation
Emit events for state transitions (PAID, DISPENSED, FAILED, REFUNDED). Track metrics like failed_dispenses, refund_rate, and time-to-refund.
Reconcile transactions daily: ensure every PAID without DISPENSED has either an open retry, FAILED, or REFUNDED state.
Edge cases to handle
Partial refunds (e.g., user charged extra fees): model refund amount on the Transaction.
Manual refunds: allow support to move a FAILED transaction to REFUNDED with an audit trail.
Payment confirmations delayed: ensure PAID is only set when the payment gateway returns a confirmed status (or after robust webhooks).

Minimal pseudocode example

Transaction purchase(user, item):
  tx = Transaction.create({state: INITIATED, user, item})
  payment = PaymentGateway.charge(user, item.price, idempotency_key=tx.id)
  if payment.success:
    tx.update(state=PAID, payment_id=payment.id)
    enqueue(DispenseWorker, tx.id)
  else:
    tx.update(state=FAILED)
    // no inventory change

DispenseWorker(tx_id):
  tx = Transaction.fetch(tx_id)
  if tx.state != PAID: return
  result = Dispenser.tryDispense(tx.item)
  if result.success:
    tx.update(state=DISPENSED, dispensed_at=now)
    Inventory.decrement(tx.item_id)
  else:
    tx.update(state=FAILED, failure_reason=result.error)
    enqueue(RefundWorker, tx.id)

RefundWorker(tx_id):
  tx = Transaction.fetch(tx_id)
  if tx.state != FAILED and tx.state != PAID: return
  if tx.refund_id: return  // idempotent
  refund = PaymentGateway.refund(tx.payment_id, idempotency_key=tx.id + "-refund")
  if refund.success:
    tx.update(state=REFUNDED, refund_id=refund.id)

Testing checklist

Simulate successful payment + successful dispense (inventory decremented once).
Simulate successful payment + dispenser failure + refund (inventory unchanged, refund occurred).
Retry paths: repeated charging attempts, repeated dispense calls, repeated refund calls (idempotency).
Concurrency: simultaneous purchase requests for last item.

Summary (short)

Treat REFUND as a state in your Transaction model. Only decrement stock after DISPENSED, and only trigger refunds from PAID/FAILED. This simple rule prevents inventory drift, enforces idempotency, and makes reconciliation and monitoring tractable.

#SystemDesign #OOD #SoftwareEngineering
